rack: two half-width nodes each with dual Intel Xeon Scalable CPUs, 2× NVIDIA GPUs, 16 DDR4 slots (1 TB), NVMe boot, PCIe Gen4, redundant PSUs, BMC remote mgmt.
Overview
The FusionServer G5200 V7 packs two hot-swappable server blades into 2U. Each blade runs dual Intel® Xeon® Scalable CPUs alongside two NVIDIA GPUs. It delivers 1 TB DDR4 per node, M.2 NVMe boot, and PCIe Gen4 slots—ideal for AI inference, virtualization, and high-density edge.
Product Description
This chassis flexes on density and versatility:
-
Dual Server Blades: 2 hot-swap half-width nodes in 2U
-
CPUs per Node: 2× Intel® Xeon® Scalable (3rd-Gen)
-
GPUs per Node: 2× NVIDIA PCIe cards (A100/T4/V100)
-
Memory per Node: 16× DDR4-3200 DIMMs, up to 1 TB
-
Boot Storage: 2× M.2 NVMe per node
-
Expansion per Node: 2× PCIe Gen4 ×16 slots
-
Power: Shared dual 2000 W Platinum PSUs, N+1 redundant
-
Cooling: Hot-swap high-flow fans
-
Mgmt & Security: BMC IPMI/Web UI, TPM 2.0, chassis intrusion alert
Key Features
-
Dual-Node Design: Two servers in one 2U chassis
-
Hybrid Compute: CPU + 2 GPUs per blade for mixed workloads
-
1 TB DDR4 per blade for data-heavy apps
-
NVMe Boot: M.2 bays for rapid OS load
-
PCIe Gen4: High-speed slots for NICs/accelerators
-
Redundant PSUs & Fans: Zero-downtime serviceability
-
Remote Ops: Full BMC control & monitoring
Specifications
| Spec |
Detail |
| Form Factor |
2U rack |
| Server Blades |
2 hot-swap half-width nodes |
| CPUs (per Blade) |
2× Intel® Xeon® Scalable (3rd-Gen) |
| GPUs (per Blade) |
2× NVIDIA PCIe cards (A100/T4/V100) |
| Memory (per Blade) |
16× DDR4-3200 DIMMs, up to 1 TB |
| Boot Bays (per Blade) |
2× M.2 NVMe |
| Expansion (per Blade) |
2× PCIe Gen4 ×16 |
| Power Supplies |
2× 2000 W Platinum (1+1 redundant) |
| Cooling |
Hot-swap high-flow fans |
| Network |
1× 1 GbE BMC per blade; optional OCP for 10/25 GbE |
| Security |
TPM 2.0 per blade; chassis intrusion detection |
| Management |
BMC IPMI/Web UI/CLI |
| Dimensions |
438 × 88.5 × 766 mm |
| Weight |
~32 kg (full config) |
Supported OS / Apps / Industries
-
OS: RHEL, Ubuntu, VMware ESXi, Windows Server
-
Apps: AI inference, virtualization, HPC, edge services
-
Industries: Cloud, finance, telecom, enterprise IT
Benefits & Compatibility
-
High Density: 2 nodes in 2U saves rack space
-
Balanced Power: CPU + GPU per blade for hybrid tasks
-
Fast Boot: NVMe for instant OS & scratch storage
-
Future-Ready I/O: PCIe Gen4 for latest cards
-
Nonstop Uptime: Redundant PSUs/fans & enterprise RAS
-
Easy Management: Out-of-band BMC for firmware, BIOS, health
Purpose of Use
Perfect for AI/ML inference clusters, VDI farms, micro-service blades, and converged CPU+GPU workloads in dense environments.
How to Use
-
Rack-mount the 2U chassis.
-
Slide in each server blade and connect its BMC LAN.
-
Populate CPUs, GPUs, memory, and M.2 drives per blade.
-
Install I/O cards in blade PCIe slots.
-
Power on and configure via BMC console.
-
Deploy OS, hypervisor, or AI frameworks.
Packaging / Weight / Dimensions
-
Dimensions: 438 × 88.5 × 766 mm (2U)
-
Weight: ~32 kg (full config)
-
Includes: Chassis, blades, power cords, rail kit
Warranty & FAQs
Warranty: 3 years next-business-day support.
FAQs:
-
Q: Are blades hot-swappable?
A: Yes, you can swap each blade under power.
-
Q: Total GPU count?
A: 4 GPUs (2 per blade).
Performance & Reliability
Built with enterprise-grade parts and advanced RAS. Hot-swap modules and proactive health monitoring ensure 24/7 uptime.
Best Price Guarantee
Found a lower price? Show proof and we’ll match it—anywhere in the UAE.
Shop Today & UAE Delivery
Order now for secure, tracked shipping to Dubai, Abu Dhabi, Sharjah, and all Emirates.
Customer Reviews & Testimonials
Deployed the G5200 V7? Leave a review to guide peers—and get featured!
After-Sales Support
24/7 expert help via chat, email, or phone. From blade setup to GPU tuning, we’ve got you.
Get in Touch
Need custom configs or quotes? Hit us up via live chat, email, or phone. We’re here 🤙.
Stock Availability
This hybrid model moves fast. Contact us to confirm availability before checkout.
Disclaimer
All specs and info subject to change without notice. Images are illustrative. Confirm details with our sales team before purchase.
