Reflective IR sensor: 10–100 mm range, 0.2 ms response, NPN/PNP output, 10–30 V DC, IP64 housing, M8 connector—fast object sensing.
Overview
The JRP-2RA1 is a compact single-beam infrared sensor for quick object detection. It sees targets from 10 mm to 100 mm with ±0.5 mm repeatability and 0.2 ms response time. Its digital NPN/PNP output plugs right into your PLC or MCU.
Product Description
• Single-Beam IR: One emitter/receiver pair for straightforward sensing
• Range: 10–100 mm, adjustable via onboard potentiometer
• Repeatability: ±0.5 mm for reliable detection
• Response Time: 0.2 ms for high-speed conveyors
• Output: Selectable NPN or PNP digital switch
• Supply: 10–30 V DC @ 10 mA
• Housing: IP64 dust-proof metal body, resin-filled for vibration
• Connector: 4-pin M8 quick-disconnect (cable included)
• Indicator: Integrated LED for power & detect status
Just mount it, wire power and output, and start reading clean digital signals.
Key Features
-
Wide Range: 10–100 mm covers varied object sizes
-
Fast Response: 0.2 ms for rapid automation cycles
-
Selectable Output: NPN or PNP via DIP switch
-
Rugged Design: IP64-rated metal housing for harsh zones
-
Plug-and-Play: M8 connector and LED feedback
Specifications
| Spec |
Detail |
| Sensing Mode |
Reflective IR, single-beam |
| Range |
10 – 100 mm |
| Repeatability |
±0.5 mm |
| Response Time |
0.2 ms |
| Output |
NPN/PNP selectable digital switch |
| Supply Voltage |
10–30 V DC |
| Current Draw |
10 mA |
| Housing Rating |
IP64 |
| Connector |
4-pin M8 quick-disconnect |
| Dimensions |
45×20×15 mm (L×W×H) |
| Weight |
~25 g |
| Operating Temp. |
–20 °C to +60 °C |
Supported Platforms & Use Cases
-
Interfaces: PLC digital inputs, microcontrollers (Arduino, Raspberry Pi)
-
Use Cases: Conveyor part detection, bin-full alarms, end-of-line presence
Benefits & Compatibility
-
Easy Integration: Direct digital output into your control system
-
Reliable Sensing: Stable single-beam design rejects minor reflections
-
Quick Setup: DIP-selectable output and LED confirmation
-
Industrial-Grade: IP64 protection and resin fill survive dust/vibration
Purpose of Use
Ideal for assembly-line part presence checks, packaging verification, and basic object sensing.
How to Use
-
Mount sensor facing target object.
-
Wire VCC to 10–30 V, GND, and output to your PLC/MCU.
-
Select NPN or PNP mode via DIP switch.
-
Power on; LED lights when object detected.
-
Read digital on/off signal in your control logic.
Packaging & Dimensions
-
Includes: JRP-2RA1 sensor, 2 m M8 cable, mounting bracket, quick-start guide
-
Size: 45×20×15 mm (L×W×H)
-
Weight: ~25 g
Warranty & FAQs
Warranty: 1-year limited.
FAQs:
Performance & Reliability
Features temperature-compensated electronics and sealed optics. Rated for 10 million actuation cycles.
