Dual-beam optical sensor: 10–200 mm range, 2 mA power, 0.1 ms response, digital output, 3.3–5 V VCC, rugged IP64 housing—ideal for automation.
Overview
The JRP-2RAY is a compact dual-beam reflective infrared sensor. It senses objects from 10 mm up to 200 mm away with < 0.1 ms response. Built-in digital output makes integration easy. Perfect for assembly lines, packaging, and robotics.
Product Description
• Dual-Beam IR: Two parallel emitters for cross-checking and noise rejection
• Range: 10 mm–200 mm with ±1 mm accuracy
• Response Time: < 0.1 ms for high-speed detection
• Output: NPN/PNP digital switch selectable
• Supply: 3.3–5 V DC @ 2 mA
• Housing: IP64 dust-proof, resin-filled for vibration
• Connector: 4-pin M8 quick-disconnect for plug-and-play
• Indicator: Built-in LED for power & detection status
Slide it on your bracket, wire VCC/GND, and read the output—object detection, simplified.
Key Features
-
Dual-Beam Design: Rejects ambient light and reduces false triggers
-
Fast Response: 0.1 ms for high-speed automation
-
Wide Range: 10–200 mm sensing distance
-
Selectable Output: NPN or PNP digital mode
-
Compact & Rugged: IP64-rated metal housing
-
LED Indicators: Visual power and detect feedback
Specifications
| Spec |
Detail |
| Sensing Mode |
Reflective infrared, dual-beam |
| Range |
10 – 200 mm |
| Accuracy |
±1 mm |
| Response Time |
< 0.1 ms |
| Supply Voltage |
3.3–5 V DC |
| Current Draw |
2 mA |
| Output |
NPN/PNP selectable digital switch |
| Housing Rating |
IP64 |
| Connector |
4-pin M8 quick-disconnect |
| Operating Temp. |
–20 °C to +60 °C |
| Dimensions |
30×20×10 mm (L×W×H) |
| Weight |
~15 g |
Supported Platforms & Use Cases
-
Interfaces: PLCs, microcontrollers (Arduino, Raspberry Pi)
-
Use Cases: Object detection, part counting, end-of-travel sensing, safety light curtains
Benefits & Compatibility
-
Easy Integration: 4-pin M8 plug, digital output directly interfaces to logic
-
High Reliability: Dual-beam rejects dust and reflections
-
Speed & Precision: Fast response and fine accuracy
-
Industrial-Grade: Rugged IP64, wide temp range
-
Flexible Mounting: Compact size fits tight spaces
Purpose of Use
Ideal for conveyor monitoring, pick-and-place robotics, packaging lines, and safety interlocks.
How to Use
-
Mount sensor facing target area.
-
Wire VCC to 3.3–5 V, GND, and output to controller.
-
Select NPN or PNP mode via DIP switch.
-
Power on; LED glows when object detected.
-
Read digital output in your control logic.
Packaging & Dimensions
-
Includes: JRP-2RAY sensor, mounting bracket, M8 connector cable, quick-start sheet
-
Size: 30×20×10 mm (L×W×H)
-
Weight: ~15 g
Warranty & FAQs
Warranty: 1-year limited.
FAQs:
Performance & Reliability
Built with precision optics and temperature-compensated electronics. Rated for > 10 million cycles.
Best Price Guarantee
Found a lower distributor price? Show proof—we’ll match it UAE-wide.
Shop Now & UAE Delivery
Order today for express shipping to Dubai, Abu Dhabi, Sharjah, and all Emirates.
Customer Reviews & Testimonials
Using the JRP-2RAY? Share your story—get featured on our site!
After-Sales Support
24/7 expert help via chat, email, or phone. From wiring to tuning, we’ve got you.
Get in Touch
Need bulk quotes or custom firmware? Hit us up via live chat, email, or phone. We’re here 🤙.
Stock Availability
High-volume orders possible; stock moves fast. Contact us to confirm before ordering.
Disclaimer
All specs subject to change without notice. Images are illustrative. Verify details with our sales rep before purchase.
