2U rack: dual Intel Xeon Scalable CPUs, 32 DDR4 slots (2 TB), 8×3.5″ HDD bays, 4 NVMe bays, PCIe Gen4, redundant PSUs, BMC remote mgmt.
Overview
The FusionServer 5885H V7 merges massive storage and compute in 2U. It hosts dual Intel® Xeon® Scalable CPUs, up to 2 TB DDR4, plus eight 3.5″ HDD bays and four NVMe boot bays. It nails database, file-server, and virtualization workloads with enterprise reliability.
Product Description
This chassis crushes data-heavy tasks with:
-
CPUs: 2× Intel® Xeon® Scalable (3rd-Gen) up to 28 cores each
-
Memory: 32× DDR4-3200 DIMMs, up to 2 TB
-
Storage: 8× hot-swap 3.5″ HDD bays (SATA/SAS) + 4× front NVMe M.2 bays
-
Expansion: 6× PCIe Gen4 ×16 slots for NICs, HBAs, or GPUs
-
Power: Dual 1600 W Platinum PSUs, N+1 redundant
-
Cooling: Hot-swap high-flow fans optimized for heavy loads
-
Mgmt & Security: BMC IPMI/Web UI, TPM 2.0, chassis intrusion alert
Key Features
-
Massive Capacity: 8× 3.5″ bays + 4 NVMe boot bays
-
Dual Xeon CPUs: High core counts for databases
-
2 TB DDR4: Memory-hungry in-memory apps
-
PCIe Gen4: Next-gen I/O in six slots
-
Redundant PSUs & Fans: Zero-downtime serviceability
-
Remote BMC: Out-of-band firmware, BIOS & health mgmt
Specifications
| Spec |
Detail |
| Form Factor |
2U rack |
| Processors |
2× Intel® Xeon® Scalable (3rd-Gen) |
| Memory |
32× DDR4-3200 DIMMs, up to 2 TB |
| 3.5″ Drive Bays |
8× hot-swap (SATA/SAS) |
| NVMe Bays |
4× M.2 front NVMe |
| PCIe Expansion |
6× PCIe Gen4 ×16 |
| Network |
1× 1 GbE BMC + optional OCP for 10/25 GbE NICs |
| Power Supplies |
2× 1600 W Platinum (1+1 redundant) |
| Cooling |
Hot-swap high-flow fans |
| Security |
TPM 2.0, chassis intrusion detection |
| Management |
BMC IPMI / Web UI / CLI |
| Dimensions (WxHxD) |
438 × 88.5 × 766 mm |
| Weight |
~34 kg |
Supported OS / Applications / Industries
-
OS: Windows Server, VMware ESXi, RHEL, SUSE, Ubuntu
-
Applications: File/Print, database, virtualization, backup/archiving
-
Industries: Enterprise storage, finance, healthcare, telecom
Benefits & Compatibility
-
High Storage Density: 8× 3.5″ bays + NVMe boot in 2U
-
Balanced Compute: Dual CPUs + ample memory
-
Future-Ready I/O: PCIe Gen4 for add-on cards
-
Always-On: Redundant PSUs/fans & enterprise RAS
-
Easy Ops: BMC remote console streamlines management
-
Scalable: Mix HDD/SAS/NVMe per workload
Purpose of Use
Ideal for large-scale file-server clusters, SQL/NoSQL databases, virtual machine hosts, and backup/archival nodes.
How to Use
-
Rack-mount in a 2U slot.
-
Populate CPUs, memory, HDDs, and NVMe modules per quick-start guide.
-
Connect power, network, and BMC port.
-
Configure BIOS/RAID via BMC UI or CLI.
-
Deploy your storage or virtualization platform.
Packaging / Weight / Dimensions
-
Dimensions: 438 × 88.5 × 766 mm (2U)
-
Weight: ~34 kg (fully loaded)
-
Includes: Chassis, drive trays, PSUs, rack rails, quick-start guide
