Dual-beam IR sensor: 5–200 mm range, 0.1 ms response, 0–10 V analog output + NPN/PNP, 5–30 V DC, IP64 housing, M8 connector—fast object detection.
Overview
The JRP-2RA2 packs two IR beams for stable, noise-free detection. It senses from 5 mm up to 200 mm with ±0.5 mm repeatability and a blazing 0.1 ms response. Dual analog (0–10 V) and digital (NPN/PNP) outputs make it super flexible. Ideal for conveyors, pick-and-place, and presence sensing.
Product Description
• Dual-Beam IR: Twin emitters boost immunity to ambient light
• Range: 5–200 mm with ±0.5 mm repeatability
• Response Time: 0.1 ms for high-speed lines
• Outputs: 0–10 V analog + selectable NPN/PNP digital
• Supply: 5–30 V DC @ 3 mA
• Housing: IP64 dust-proof, resin-filled for vibration
• Connector: 4-pin M8 quick-disconnect (cable included)
• Indicator: Bicolor LED shows power & detect status
Mount it, wire VCC/GND and outputs, then stream analog and digital signals to your PLC or MCU—no fuss.
Key Features
-
Dual-Beam Design: Cuts false trips from dust or glare
-
Ultra-Fast: 0.1 ms response for rapid automation
-
Wide Range: 5–200 mm covers varied objects
-
Hybrid Outputs: 0–10 V analog + NPN/PNP switch
-
Rugged Build: IP64 metal housing for harsh lines
-
Plug-and-Play: M8 connector and LED feedback
Specifications
| Spec |
Detail |
| Sensing Mode |
Reflective IR, dual-beam |
| Range |
5 – 200 mm |
| Repeatability |
±0.5 mm |
| Response Time |
0.1 ms |
| Analog Output |
0–10 V DC |
| Digital Output |
NPN/PNP selectable |
| Supply Voltage |
5–30 V DC |
| Current Draw |
3 mA |
| Housing Rating |
IP64 |
| Connector |
4-pin M8 quick-disconnect |
| Dimensions |
35×20×12 mm (L×W×H) |
| Weight |
~20 g |
| Operating Temp. |
–20 °C to +60 °C |
Supported Platforms & Use Cases
-
Interfaces: PLC analog/digital inputs, Arduino, Raspberry Pi
-
Use Cases: Conveyor part detection, end-of-line presence, bin fill monitoring
Benefits & Compatibility
-
Stable Detection: Dual beams reject noise and flicker
-
Fast & Precise: 0.1 ms and ±0.5 mm for tight tolerances
-
Dual Signals: Stream analog distance and digital trigger
-
Industrial-Grade: IP64 & resin fill survive dust and vibration
-
Easy Setup: M8 cable, LED feedback, no extra tools
Purpose of Use
Perfect for assembly-line part counting, packaging checks, and robotic pick-and-place verification.
How to Use
-
Mount sensor facing your target.
-
Wire VCC to 5–30 V, GND, analog output, and digital output to your controller.
-
Select NPN or PNP mode via onboard DIP.
-
Power on; LED glows on detection.
-
Read analog 0–10 V for distance or digital on/off for presence.
Packaging & Dimensions
-
Includes: JRP-2RA2 sensor, 2 m M8 cable, mounting bracket, quick-start guide
-
Size: 35×20×12 mm (L×W×H)
-
Weight: ~20 g
Warranty & FAQs
Warranty: 1-year limited.
FAQs:
Performance & Reliability
Features temperature-compensated optics and sealed electronics. Rated for > 10 million detection cycles.
